Incremental Encoder Baumer POG 10 DN 1000 I 9 TO 30 VDC BAUMER

The Baumer POG 10 DN 1000 I Incremental Encoder (9–30 VDC)

is a heavy-duty rotary encoder designed for precise speed and position feedback in industrial automation systems. It belongs to the robust POG 10 series by Baumer Hübner, known for reliability in harsh environments such as steel plants, cranes, and heavy machinery.

This encoder provides a resolution of 1000 pulses per revolution (PPR), enabling accurate motion control and feedback. It operates on an optical sensing principle and generates incremental signals (K1, K2, and zero pulse), which are widely used in PLCs, drives, and control systems.

The unit supports a 9–30 VDC power supply and typically outputs HTL (high-level) signals with inverted channels, ensuring strong signal transmission even over long cable distances.

Mechanically, the encoder features a solid shaft (≈11 mm) with a B10 EURO flange mounting, making it suitable for direct coupling to motors and rotating shafts. Its rugged design includes:

• Dual bearing system for extended life
• High resistance to shock and vibration
• Protection class up to IP66 for industrial environments

The encoder is capable of operating at speeds up to 12,000 rpm, making it suitable for high-speed applications.

? Key Features

• Resolution: 1000 pulses per revolution (PPR)
• Supply voltage: 9–30 VDC
• Output signals: HTL (K1, K2, zero pulse + inverted)
• Heavy-duty construction for harsh environments
• Solid shaft (~11 mm) with B10 EURO flange
• High shock and vibration resistance
• Operating speed up to 12,000 rpm
• Protection class up to IP66
• Wide temperature range (approx. -30°C to +100°C)

⚙️ Applications

• Steel and metal processing plants
• Cranes and hoisting equipment
• Electric motors and drives
• Conveyor systems
• Heavy machinery and industrial automation
• Power plants and mining equipment

? Notes

• Model: POG 10 DN 1000 I
• Encoder type: Incremental (optical)
• Output options: HTL / TTL depending on configuration
• Terminal box connection (rotatable design)
• Designed for long service life in continuous-duty environments

? Simple Explanation

? This device is attached to a rotating shaft and tells the control system how fast and how far something is rotating, helping machines run accurately.
